Description
Features:
- 1/2.7" 5MP PS CMOS Image Sensor (0.9407cm)
- Max 25/30fps@5MP
- DWDR, 2D-DNR, AWB, AGC, BLC, HLC
- 3.6mm Fixed Lens
- Illumination Range of 20 Mtrs, IP67
- CVI/CVBS/AHD/TVI switchable
Specifications:
| Image Sensor | 1/2.7" 5MP PS CMOS (0.9407cm) |
| Minimum Illumination | 0.005Lux/F1.6, 0Lux White Light on |
| BodyType | Dome |
| Shutter Speed | PAL: 1/25~1/100000s NTSC: 1/30~1/100000s |
| Max Aperture | F1.6 |
| White Balance | Auto/Manual |
| Lens Type | Fixed |
| Lens | 3.6mm |
| Gain Control (AGC) | Auto/Manual |
| DORI Distance | 3.6mm: 80m(Detect), 32m(Observe), 16m(Recognize), 8m(Identify) |
| Angle of View | 3.6 mm: 109° × 92° × 48° (diagonal × horizontal × vertical) |
| S/N Ratio | >65dB |
| Back Light Comp. | BLC/ HLC/ DWDR |
| Video Streaming | CVI: PAL: 5M@25 fps; 4M@25 fps; 1080P@25 fps; NTSC: 5M@25 fps; 4M@30 fps; 1080P@30 fps; AHD: PAL: 4M@25 fps; NTSC: 4M@30 fps TVI: PAL: 4M@25 fps; NTSC: 4M@30fps CVBS: PAL: 960H; NTSC: 960H |
| Privacy Mask | Off/On (8 area, rectangle) |
| Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| Illumination Distance | LED Range of 20 Mtr., Smart Light |
| Operating Temperature | -40°C to +55°C; <95% (non condensation) |
| Power Source | 12V DC ±30% |
| Power Consumption | Max 3.0W (12V DC, White Light on) |
| Weatherproof Standard | IP67 |
| Dimension | φ97 mm × 86.6 mm |
| Casing | Plastic |
| Weight | n/a |
